Basic Parsing Techniques

Parsers (Syntax Analyzer)

A parser is a component of the compiler that analyzes the syntactic structure of a program using a context-free grammar (CFG).

Role of Parser

• Takes tokens from lexical analyzer
• Checks grammar correctness
• Constructs parse tree / syntax tree
• Reports syntax errors

Types of Parsers

Basis	Classification
Direction of parsing	Top-down, Bottom-up
Parsing method	Predictive, Shift-Reduce
Automation	Manual, Automatic (LR)

Shift-Reduce Parsing (Bottom-Up Parsing)

Shift-Reduce Parsing is a bottom-up parsing technique that builds the parse tree from leaves to root.

Core Idea

• Reduce input string to start symbol
• Uses a stack and input buffer

Basic Operations

Operation	Description
Shift	Push input symbol to stack
Reduce	Replace RHS of production with LHS
Accept	Successful parsing
Error	Invalid syntax

Example (Conceptual)

Grammar:

E → E + T | T
T → id

Input:

id + id

Conflicts in Shift-Reduce Parsing

Conflict	Meaning
Shift-Reduce Conflict	Unclear whether to shift or reduce
Reduce-Reduce Conflict	Multiple reductions possible

Operator Precedence Parsing

Operator Precedence Parsing is a special form of shift-reduce parsing that handles expressions with operators.

Key Characteristics

• Works only with operator grammars
• Uses precedence relations

Operator Precedence Relations

Relation	Meaning
<	Lower precedence
>	Higher precedence
=	Equal precedence

Advantages

• Simple to implement
• Efficient for arithmetic expressions

Limitation

• Cannot parse general CFGs

Top-Down Parsing

Top-Down Parsing constructs the parse tree from root to leaves.

Characteristics

• Starts with start symbol
• Tries to derive input string
• Uses leftmost derivation

Problem

• Left recursion
• Backtracking

Predictive Parsing

Predictive Parsing is a top-down parsing technique without backtracking.

Requirements

• Grammar must be LL(1)
• Uses parsing table

Components

Component	Description
Stack	Stores grammar symbols
Input buffer	Tokens
Parsing table	Decision guide

Advantages

• Fast
• Deterministic
• Easy error detection

Automatic Construction of Efficient Parsers

Manual construction of parsers is complex. Hence automatic parser generators are used.

Examples

• YACC
• Bison

These tools generate LR parsers automatically.

LR Parsers

LR Parser is a bottom-up parser that reads input Left-to-right and produces Rightmost derivation in reverse.

Why LR Parsers Are Powerful

• Handle large class of grammars
• Detect syntax errors early
• Used in real compilers

Types of LR Parsers

Type	Description
LR(0)	Simplest
SLR(1)	Uses FOLLOW sets
CLR(1)	Canonical LR
LALR(1)	Efficient and compact

Canonical Collection of LR(0) Items

LR(0) Item

An LR(0) item is a production with a dot (.) indicating parsing position.

Example:

A → α . β

Purpose

• Represents parser states
• Used to construct ACTION and GOTO tables

Steps to Construct Canonical Collection

• Augment the grammar
• Create initial item with dot at start
• Apply Closure()
• Apply Goto()
• Repeat until no new items

Closure Operation

Adds all productions for a non-terminal appearing after dot.

GOTO Operation

Moves dot over a grammar symbol to generate new state.

Canonical Collection Table (Conceptual)

State	Items
I₀	S' → .S
I₁	S → a.S
I₂	S → a

Comparison of Parsing Techniques

Technique	Direction	Grammar Type	Complexity
Predictive	Top-Down	LL(1)	Low
Shift-Reduce	Bottom-Up	CFG	Medium
Operator Precedence	Bottom-Up	Operator Grammar	Medium
LR	Bottom-Up	Most CFGs	High

Exam-Oriented Summary

Topic	Key Point
Parser	Syntax checking
Shift-Reduce	Stack-based bottom-up
Operator Precedence	Expression parsing
Top-Down	Root to leaves
Predictive	No backtracking
LR Parser	Powerful bottom-up
LR(0) Items	Parser states

Constructing SLR (Simple LR) Parsing Tables

SLR parsing is an improvement over LR(0) parsing. It uses FOLLOW sets to resolve reduce actions and eliminate some conflicts.

Steps to Construct an SLR Parsing Table

1. Augment the grammar
   Add a new start symbol:

   S' → S


2. Construct the Canonical Collection of LR(0) items

3. Compute FOLLOW sets for all non-terminals

4. Fill ACTION and GOTO tables

   • If A → α . a β and a is a terminal → Shift

   • If A → α . → Reduce using FOLLOW(A)

   • If S' → S . → Accept

Characteristics of SLR

Feature	Description
Grammar power	More than LR(0)
Conflict handling	Uses FOLLOW sets
Table size	Smaller
Limitation	Cannot handle all CFGs

Constructing Canonical LR (CLR / LR(1)) Parsing Tables

Canonical LR parsing is the most powerful LR technique. It uses LR(1) items with lookahead symbols.

LR(1) Item Format

[A → α . β , a]

Where:

• a is a lookahead terminal

Steps for CLR Table Construction

• Augment grammar
• Construct Canonical Collection of LR(1) items
• Apply Closure and GOTO operations
• Build ACTION and GOTO tables using lookaheads

Characteristics of CLR

Feature	Description
Grammar power	Maximum
Conflict resolution	Very strong
Table size	Very large
Practical use	Rare (memory heavy)

Constructing LALR (Look-Ahead LR) Parsing Tables

LALR parsing combines the power of CLR with the compact size of SLR.

Construction Method

• Construct Canonical LR(1) collection
• Merge states having same LR(0) core
• Combine lookahead sets
• Construct ACTION and GOTO tables

Why LALR Is Popular

Feature	LALR	CLR
Grammar power	High	Very High
Table size	Small	Large
Used in practice	Yes	Rare

Most compiler tools (YACC) use LALR parsing.

Using Ambiguous Grammars in LR Parsing

An ambiguous grammar produces multiple parse trees for the same input string.

Example

E → E + E | E * E | id

Expression:

id + id * id

Problems in Parsing Tables

• Shift-Reduce conflicts
• Reduce-Reduce conflicts

Handling Ambiguity

• Rewrite grammar (preferred)
• Use precedence and associativity rules
• Use parser-generator directives

Automatic Parser Generator

An automatic parser generator is a tool that automatically constructs parsing tables and parser code from grammar rules.

Examples

Tool	Parsing Technique
YACC	LALR(1)
Bison	LALR / GLR
ANTLR	LL(*)

Advantages

• Reduces manual effort
• Reliable and efficient
• Used in real-world compilers

Implementation of LR Parsing Tables

LR parsing tables consist of two main parts:

(a) ACTION Table

Input	Action
Terminal	Shift / Reduce / Accept

(b) GOTO Table

Input	Transition
Non-terminal	Next State

LR Parsing Algorithm (Conceptual)

• Initialize stack with state 0
• Read input symbol
• Consult ACTION table
• Perform shift or reduce
• Update stack using GOTO
• Continue until accept or error

Comparison of LR Parsing Techniques

Feature	SLR	LALR	CLR
Grammar power	Medium	High	Very High
Table size	Small	Small	Large
Conflict handling	Limited	Good	Best
Practical use	Low	Very High	Low

Exam-Oriented Summary Table

Topic	Key Points
SLR Parsing	FOLLOW-based reduce actions
CLR Parsing	LR(1) lookaheads
LALR Parsing	Merged LR(1) states
Ambiguous Grammar	Causes conflicts
Parser Generator	Automates parser creation
LR Tables	ACTION + GOTO
